Overview
Quick Details
- Condition:
-
New
- Dimensions(L*W*H):
-
1850mm/2650mm/3250mm
- Plate Type:
-
Flatbed Printer
- Weight:
-
500 KG
- Automatic Grade:
-
Automatic
- Color & Page:
-
Multicolor
- Usage:
-
Cloths Printer
- Voltage:
-
380V
- Applicable Industries:
-
Manufacturing Plant, Printing Shops, Other
- Warranty:
-
1 Year
- Print Dimension:
-
300mm*500mm
- Ink Type:
-
Sublimation Ink
- Key Selling Points:
-
Multi Color
- Marketing Type:
-
New Product 2021
- Machinery Test Report:
-
Provided
- Video outgoing-inspection:
-
Provided
- Warranty of core components:
-
6 Months
- Core Components:
-
Other
- After-sales Service Provided:
-
Engineers available to service machinery overseas
- Print Speed:
-
116sqm/h,180sqm/h,230sqm/h,460sqm/h
- Ink type:
-
Reactive, Acid, Sublimation, Pigment ink
- Ink colors:
-
10colors: C,M,Y, K, LC, LM, Grey, Red, Orange, Blue
- Printing Material:
-
Knitted or woven cotton, linen, silk, wool, polyester, nylon etc.
- Max.Fabric Width:
-
1850mm/2650mm/3250mm
- RIP Software:
-
Wasatch/ Neo Stampa/ Texprint
- After Warranty Service:
-
Video technical support$138,000.00 – $550,000.00/ unit|1Â unit/units(Min. Order)
Supply Ability
Advantage Kyocera printhead high speed industrial grade print nozzles, to better meet industrial production needs. Using magnetic suspension linear motor for high printing accuracy. The application of negative pressure ink control system and ink degassing system greatly enhances inkjet stability. Equipped with automatic belt cleaning system to ensure continuous production and improve the production efficiency. Active take-up/ unwinding structure to ensure stable stretch and shrinkage of the fabric. So that in final appearance of the pattern is not deformed.
|
Textile belt printer with Kyocera heads
|
||||
|
Model
|
CO-KJ4
|
|||
|
Print head
|
Kyocera printhead
|
|||
|
Print head qty
|
4pcs/6pcs/8pcs/16pcs
|
|||
|
Printing width
|
1800mm/2600mm/3200mm
|
|||
|
Max fabric width
|
1850mm/2650mm/3250mm
|
|||
|
Suitable fabrics thickness
|
2~30mm adjustable
|
|||
|
Suitable fabrics types
|
Knitted or woven cotton, linen, silk, wool, polyester, nylon etc.
|
|||
|
Ink type
|
Reactive, Acid, Sublimation, Pigment ink
|
|||
|
Ink colors
|
10colors: C, M, Y, K, LC, LM, Grey, Red, Orange, Blue
|
|||
|
Printing Speed
|
Print head qty
|
600*600dpi (Production mode 2pass)
|
||
|
4heads
|
116sqm/h
|
|||
|
6heads
|
180sqm/h
|
|||
|
8heads
|
230sqm/h
|
|||
|
16heads
|
460sqm/h
|
|||
|
Cleaning Method
|
Auto negative cleaning system & auto scraping device
|
|||
|
Take up and Drying
|
Belt continuous transport, automatic fabric taking up system, infrared dryer
|
|||
|
Work Station
|
Win10 64bit
|
|||
|
CPU:Inter Core i7 6700K
|
||||
|
HD: 1T
|
||||
|
RAM:32GB
|
||||
|
RIP Software
|
Wasatch/ Neo Stampa/ Texprint
|
|||
|
Image type
|
JPEG, TIFF, BMP file format/RGB, CMYK color mode
|
|||
|
Power
|
Supply
|
380V±10% 3Phase 5Wire
|
||
|
Frequency
|
50HZ±10%
|
|||
|
Consumption
|
Less than 16KW
|
|||
|
Compression air
|
Air flow above 0.3m3/min, Air pressure above 6KG
|
|||
|
Working Conditions
|
Temperature 18ºC-28ºC, Humidity 50%-70%
|
|||
|
Equipment Dimensions
|
1800mm
|
2600mm
|
3200mm
|
|
|
4200*3800*1900mm
|
5000*3800*1900mm
|
5600*3800*1900mm
|
||
|
Weight
|
4500kg(add dryer750kg)
|
5200kg(add dryer850kg)
|
5700kg(add dryer950kg)
|
|
Application
