Product Feature
Specification
| Type | 70t Low bed semi trailer |
| Function | Heavy equipment and other stuff |
| Weight | |
| Max Loading capacity | 70tons |
| Specification | |
| Dimensions(L*W*H) | 17000*3000*3300mm |
| Working deck size(L*W*H) | 13000*3000*1250mm |
| Main Beam | The height of the beam is 500 mm, upper plate is 20mm,down plate is 25mm,middle plate is 12mm. |
| Axle number | 3* 16T FUWA |
| King pin | 90mm |
| Support legs | 28Ton, two speed action |
| Tire | |
| Tire | 11.00R20 |
| Number of tire | 12 |
| Frame(specs materials) | |
| Platform plate | 4mm |
| Ladder | Two steel ladders |
| Tools box | 1 |
| Voltage | 24V |
| Receptacle | 7 ways (7 wire harness) |
| Light | |
| Side marker lamp | LED type |
Min order 1 38,000 > 2units $15,000
